Alf 1 - The complex way

This was the first try - and "rests in peace" by now !

What do you do if you want to build a robot - independent on ground surface ?

Yes exactly give him a chain drive !

Thats what i thought and built one.. or tryed to.
Chain drives are complex - i know by now.


The motors are 2 gear-motors running with 12V DC.
Two encoders were used for controlling left-right wheel speed (as in Bugrug2 later)

The bevel gear wheels exposed as the week point in the system later.


The "brain" of it all is a Z80 CPU card with this components installed:

  • Ultrasonic distance unit
  • Electronic Compass
  • Radio Datalink
  • Linear Motor driver unit with wheel encoders
  • 8 Bumpers
  • 4x20 Display unit with 6 Timers and a lot of IO Stuff.
  • Voltage supply unit for 15, 12, 5 V DC and recharge mechanism.


The mechanics were built on my EMCO lathe.
The toothed beld i bought in a special rubber shop nearby.
